CQRLOG cannot talk to or key the radio

55 posts / 0 new
Last post
dk7ob
Caution!

If you do a standard ./configure; make; sudo make install, you will get the default installation path, this usually is /usr/local. So you'll still end up with 2 rigctld versions, the original one in /usr/bin, and the new one in /usr/local/bin and you still have to modify the path to rigctld in cqrlog.

I usually avoid installation of "home built" packages in the system file system but directly use the binaries created in the build directory. That does not always work, but in this case it is OK. You only need the rigctld binary for cqrlog.

You know that cqrlog is using the hamlib 3.0.1 if you find the TS590SG in cqrlog's rig list.

WG9L
On my original machine, I

On my original machine, I installed a new, larger capicity SSD and installed all the software. A fresh install of Mint 20 and installation of MariaDB, then a clean install of CQRLog 2.4.0 (001), I have the old log database up and running without a problem. But I cannot get CQRLog to see my radio anymore.

I am running the same hardware as before when running Mint 19.2 and everything worked fine then. With Mint 20 installed, I can get FLdigi and WSJT-X to work properly and see and talk to the radio, but not CQRLog. After making the same settings as in Mint 19, CQRLog will poll the radio (I see the CAT light on the radio flash three times), but CQRLog will not display the radio frequency.

When I have CQRLog and WSJT-X running together, CQRLog reads the frequency from WSJT-X and logs it properly.

I am a member of the Dialout group.
All the hardware is the same as Mint 19.2 (except for new SSD).
Radio is Yaseu, FT-1000D (#103)
RigCtld is set the same as before (/dev/ttyS4) - also these are the same settings as FLDigi and WSJT-X.

Any thoughts? I'm at a complete loss to explain this condition.

Thanks and 73,
Bob, WG9L

Here is a copy of my of my log.txt file:

Cqrlog Ver:2.4.0 (001) Date:2019-10-27
**** DEBUG LEVEL 1 ****

OS:
Linux version 5.4.0-51-generic (buildd@lcy01-amd64-020) (gcc version 9.3.0 (Ubuntu 9.3.0-10ubuntu2)) #56-Ubuntu SMP Mon Oct 5 14:28:49 UTC 2020
SSL libraries:
libssl.so
libcrypto.so
Loaded 149346 LoTW users
Loaded 136581 eQSL users
Loaded 34579 SCP calls
*
User home directory: /home/bob/
Program home directory: /home/bob/.config/cqrlog/
Data directory: /home/bob/.config/cqrlog/database/
Memebers directory: /home/bob/.config/cqrlog/members/
ZIP code directory: /usr/share/cqrlog/zipcodes/
Binary dir: /usr/bin/
Share dir: /usr/share/cqrlog/
*
56 us states loaded
Grid map created
/usr/bin/mysqld
MySQLProcess.Executable: /usr/sbin/mysqld Parameters: --defaults-file=/home/bob/.config/cqrlog/database/mysql.cnf
--datadir=/home/bob/.config/cqrlog/database/
--socket=/home/bob/.config/cqrlog/database/sock
--port=64000

Trying to connect to database
TMySQL57Connection : Server connect failed.
Trying:1
select * from tables where table_schema = 'cqrlog_common'

SELECT log_nr,log_name FROM cqrlog_common.log_list order by log_nr

use cqrlog001

use cqrlog001

use cqrlog001

use cqrlog001

use cqrlog001

SELECT * FROM cqrlog_config

select * from db_version

[UpgradeMainDatabase] Old version: 16 cDB_MAIN_VER: 16
select * from cqrlog_common.db_version

SELECT * FROM cqrlog_common.dxcc_ref ORDER BY ADIF

SELECT * FROM cqrlog_common.dxcc_ref ORDER BY ADIF

Settings:
-----------------------------------------------------
RigCtldPath:/usr/bin/rigctld
RigCtldArgs:-m 103 -r /dev/ttyS4 -t 4532 -s 4800
RunRigCtld: TRUE
RigDevice: /dev/ttyS4
RigCtldPort:4532
RigCtldHost:localhost
RigPoll: 500
RigSendCWR: FALSE
RigId: 103

Starting RigCtld ...
rigProcess.Executable: /usr/bin/rigctld Parameters: -m
103
-r
/dev/ttyS4
-t
4532
-s
4800

rigctld started!
Connected to localhost:4532

Settings:
-----------------------------------------------------
RotCtldPath:/usr/bin/rotctld
RotCtldArgs:
RunRotCtld: FALSE
RotDevice:
RotCtldPort:4533
RotCtldHost:localhost
RotPoll: 500
RotId: 1

rotctld started!
Connected to localhost:4533
FreqmemSql:select id,freq,mode,bandwidth,info from freqmem order by id

FreqmemNR:0=16
FreqmemNR:1=17
FreqmemNR:2=18
FreqmemNR:3=19
FreqmemNR:4=20
FreqmemNR:5=21
FreqmemNR:6=22
FreqmemNR:7=23
FreqmemNR:8=24
FreqmemNR:9=25
FreqmemNR:10=26
FreqmemNR:11=27
FreqmemFirst:16 FreqmemLast:27
Sending: fmv

CW init
Device: /dev/ttyUSB0
Last error nr: 0
Last error desc:OK
After sending null command
After sending echo command: 20
Firmware version: 23
Speed: 0
Speed: 26
SELECT * FROM profiles WHERE visible > 0 ORDER BY nr

SELECT * FROM profiles WHERE nr = -1

SELECT * FROM profiles WHERE visible > 0 ORDER BY nr

SELECT * FROM profiles WHERE nr = -1

select * from view_cqrlog_main_by_qsodate where qsodate >= '2020-10-14' order by qsodate,time_on

LoadForm: frmNewQSO
Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Sending: fmv

Section:frmTRXControl
Saving window size a position (frmTRXControl) (height|width|top|left):334|317|86|211
Closing rigs...
1
1a
2
3
4
5
6
Section:frmDXCluster
Saving window size a position (frmDXCluster) (height|width|top|left):389|669|608|143
Closing Details window
Section:frmQSODetails
Saving window size a position (frmQSODetails) (height|width|top|left):124|318|451|210
Section:frmBandMap
Saving window size a position (frmBandMap) (height|width|top|left):490|278|87|532
Section:frmPropagation
Saving window size a position (frmPropagation) (height|width|top|left):76|155|119|813
Section:frmNewQSO
Saving window size a position (frmNewQSO) (height|width|top|left):767|1100|230|820
AProcess.Executable: killall Parameters: xplanet

select count(*) from cqrlog001.cqrlog_config

Saving ini file to database
WinKeyer closed
select count(*) from cqrlog001.cqrlog_config

Saving ini file to database
1
2
3
4
5
6
Closing DXCluster window
Closing TRXControl window
Closing GrayLine window
Closing dDXCC
Deleting config file: 1cqrlog.cfg
Deleting config file: cqrlog.cfg
Closing dData
/home/bob/.config/cqrlog/database/Ham-PC.pid
p.Executable: kill Parameters: 17340

PA1SBM
PA1SBM's picture
Hi,

Hi,

Please create a new topic please, this one is getting way to cluttered.

As a solution , the 590SG USB speed is standard at 115200, please try that , and make sure you are a member of the dailout group.

Alex

PA1SBM
PA1SBM's picture
Hi steve,

Hi steve,
We seem to have missed each other....

drop me an email if you still want/need my help at pa1sbm add live dot nl

73
Alex
